Lattice Girders With Concrete Flanges Floors

It consists of a single 65mm precast concrete leaf with a projecting lattice girder.

Lattice girders with concrete flanges floors. The top reinforcement mat is placed on site along with a layer of stitching reinforcement across the joint between slabs prior to pouring the in situ concrete. The fibre concrete spacer fulfils the criteria of din 1045 wu guidelines and the requirements defined in the dbv instruction sheet. The units are typically 50mm to 100mm thick and 1200mm or 2400mm wide. Fibre concrete spacers for lattice girders.

One of the most popular forms of hybrid concrete floors is the lattice girder slab system. An omnia flooring slab is a reinforced precast concrete slab which incorporates a triangular lattice girder that is attached to a lower layer of reinforcement. They are delivered as a lattice girder floor installed on the construction site and filled with cast in situ concrete. Lattice girder slabs lattice girder slabs act as permanent formwork and as precast soffits for robust high capacity composite floor slabs.

Steel wire truss lattice girder for precast concrete slab. The lattice girder floor consists of pre produced large format reinforced concrete ceiling panels at least 5 cm thick. Max frank au fibre concrete spacers and lattice girders are used for combined floor slabs and for steel fibre concrete with welded wire mesh. The lattice girder is manufactured using high strength steel wire which provides rigidity to the panel and enables it to bind easily with in situ concrete which is poured later on site.

The main bottom floor reinforcement is contained within the precast concrete leaf. Sound resistance composite lattice girder floors are suitable for use at first floor level in domestic housing to create a quiet home for the benefit of home owners their families and neighbours. Precast concrete lattice girder floor. The top reinforcement is fixed in situ.

Use of lattice girders in reinforced concrete floor plates is a widely practiced method of construction for conventional high rise building. Composite lattice girder floors are usually designed with a minimum 1hour fire resistance although periods of up to 4 hours are possible. Slab system for constructing concrete slabs. Truss girders have a triangular shape are electro welded and have three defo.

Truss girder lattice are mainly used for the prefabrication of concrete planks a medullar element in the hallow block floor. The major advantage of this system is that it is an in situ structure one way or two way spanning. A floor system that serves as an alternative to conventional concrete in place floors in which a prefabricated slab with reinforcement serves as a permanent formwork for the final casting of the floors.
